OTIS DISPLAYS

Ver. 1 Rel. 08.03.15

BLUE BACKGROUND LIQUID CRYSTAL DISPLAY | 1½ (40 mm) LCD DISPLAY

Blue Liquid Crystal Display indicator with dual digits and arrow for floor position as well as car direction. Any alphanumeric character and up/down arrows can be displayed in either single or double digit floor designations.

Typical Applications:

> Car-OP Panel
> Transom
> Car and hall fixtures

Features:

> Long life LED backlighting
> Fast, 4-wire hookup
> Self testing
> Alternate message
> Passing chime output
> Error detection and correction feature
> Otis 411 car data link hook up
> No R55 card needed
> Deep blue crystal with white back light

Dimensions:

> 6.50"W x 2.70"H x 1.625"D     |     1.5" LCD DISPLAY

Color Available:

Note:

Otis car data link interface elevonic 411-style controls

VIEW: CATALOG PAGE
